Description
[Publish 20161001]
New Version Super Ultra Compact Pan/Tilt Camera Mount
Old Version: V1
https://pinshape.com/items/194...
https://pinshape.com/items/977...
This pan-tilt kit is the perfect way to give your project full range motion with two micro servos. The pan-tilt can rotate roughly 180° from side-to-side and can tilt up&downwards around 180°. Using two Micro Servos. (Turnigy TG9G, Tower Pro SG90 or SG-92 type)
2 x 9G Servos 4 x 2mm 5mm Tapping screws [For Servo mount] 2 x 2mm 7mm Tapping screws [For Servo hone mount] 2 x M2 6mm [For pan tilt shaft mount] 4 x M2 10mm [For camera mount] 7 x M2 12mm [For base case mount] 3 x M2 Nuts [For base case mount] 4 x M3 15mm [For vert mount]
Two type: Stand alone and PAN servo landfill type
I look forward to seeing your build !! Enjoy!
The open source SUCPT Cam hardware is free and made with love. Please show your level of support with a voluntary donation.
Donate: https://www.paypal.com/cgi-bin...
Zalophus's DesignHouse: http://zalophus.tistory.com/ and https://zddh.blogspot.com/
