GoPro Tripod Adapter Mount

Prints (0)

Description

SummaryI remixed these as the nuts were always being pulled out when the GoPro is tripod screw is torqued. These mounts allow use of standard and lock-nuts and the nuts will not slip when tightened. Marked as W.I.P. since I have not tested the STD Nut adapter model as I only have a lock-nut handy. If I can find a standard 1/4-20 nut I will adjust the dimensions in the model to reflect proper sizing (if needed). I've included the .skp files for easier editing/remixing. Depending on your tripod, a longer bolt may be required. Sadly, the bolt on my cheapo tripod is too short but its nothing that can't be fixed with a quick trip to the hardware store (or a parts bin of mine!)Print SettingsPrinter: FFCP, Dup4Rafts: Doesn't MatterSupports: YesInfill: 20%+

Design Files

File Size

GoPro_Tripod_adapter-_STD_Nut.stl
1.37 MB
GoPro_Tripod_adapter-_Lock_Nut.stl
1.38 MB
