L-menthol, C10H20O, is an alcohol built on a single six-membered carbon ring carrying a hydroxyl (-OH) group: 31 atoms joined by 31 single bonds.
This is a ball-and-stick print where every sphere has its element symbol engraved into the surface, so the ten carbons, the oxygen and the twenty hydrogens are easy to tell apart without any painting. The molecule has three stereocentres (R, S, R), and the 3D shape of the ring is easy to follow in your hand. It is one solid mesh, nothing to assemble or glue.
Printing notes: the STL is exported in angstroms, so scale it up 10x in your slicer (1 angstrom becomes 10 mm). Plain PLA works fine. Add supports under the bonds and the lower spheres; a fine layer height keeps the engraved letters sharp.
Atom positions come from a computed 3D conformer. Shared under CC BY-SA 4.0, made by MolGod.
Loading prints...
L-menthol Molecule 3D Model with Engraved Atoms (CAS 2216-51-5)
Creative Commons Attribution-ShareAlike
You can distribute, remix, adapt, and build upon the material in any medium or format, as long as attribution is given and your contributions are under the same license.
Licensed under CC BY-SA
Files Included
1 downloadable file:
Downloaded: 3 times
