Arduino Ethernet AC Switcher 2CH

Prints (0)

Description

Please do you is not made if you do not understand. This things dangerous! if it is not made accurate. Please the insulation of the wiring surely. Arduino use pins. AC1 : 8pin AC2 : 9pin GND AC Wiring recommend 20AWG Wire. Ethernet Shield module W5100 Board QTY : 1 http://www.ebay.com/itm/New-Ethernet-Shield-module-W5100-Board-For-Arduino-2009-UNO-Mega-1280-2560-M21-/161633354092 AC INLET : 703W-00/08 QTY : 1 http://www.digikey.com/product-detail/en/703W-00%2F08/Q336-ND/1164207 AC OUTLET : 738W-CX2/01 QTY : 2 http://www.digikey.com/product-detail/en/738W-CX2%2F01/Q281-ND/299908 Web page that was in reference. arduino sketch http://www.storange.jp/2012/04/arduinoethernet.html SSR Switch KIT http://akizukidenshi.com/catalog/g/gK-00203/ 20/06/2015 Parts List Revision.

Design Files

File Size

AC_Switcher_top.stl
1.37 MB
AC_Switcher_bottom.stl
5.34 MB
